SNID SERIES

Industrial Dryer

  • 산업용건조기
  • 산업용건조기
  • 산업용건조기
  • 산업용건조기
  • 산업용건조기
  • 산업용건조기
  • 산업용건조기
영상보기
SNINTERNATIONAL
Industrial Dryer
SN International is a consulting firm specializing in industrial laundry equipment.

Features

  • Energy saving
    Energy saving
    Energy-efficient heat
    source(heat box, radiator)

    Increase thermal efficiency -> faster drying

    Achieve greater productivity

    Equipped with internal and external drum of excellent thermal efficiency

    Minimize heat loss for complete drying with less heat

  • Cost saving
    Self-developed drums and heat source
    devices with high thermal efficiency

    Increase drying efficiency by installing self-developed drums and heat source devices

    Faster drying with less energy -> Increase productivity & reduce energy costs

  • Increased User Convenience
    Large door and three-color working lamp

    Large doors: Easy to put in/take out large amount of laundry

    Three-color working lamp : Easy to check the status of the machine

    Lint filter screen : Easy to clean & manage

Specification sheet

Specification unit SNID-20 SNID-25 SNID-30 SNID-45 SNID-55 SNID-80 SNID-100 SNID-120 SNID-150
Capacity per 1cycle kg/cycle 20 25 30 45 50 80 100 120 150
Drum specification Diameter mm 800 900 900 1000 1150 1350 1600 1600 1800
Depth mm 800 800 950 1100 1050 1120 1000 1200 1175
Motor Drive Motor HP/kW/Pole 1/2 / 0.4 / 6 1/2 / 0.4 / 6 1/2 / 0.4 / 6 1 / 0.75 / 6 1 / 0.75 / 6 2 / 1.5 / 6 3 / 2.2 / 6 3 / 2.2 / 6 5 / 3.7 / 6
Fan Motor HP/kW/Pole 1/2 / 0.4 / 4 1/2 / 0.4 / 4 1/2 / 0.4 / 4 1/2 / 0.4 / 4 1 / 0.75 / 4 2 / 1.5 / 7 3 / 2.2 / 4 3 / 2.2 / 4 5 / 3.7 / 4
Steam heating
Piping steam in/out A/A 15 / 15 15 / 15 15 / 15 15 / 15 20 / 20 20 / 20 25 / 25 25 / 25 32 / 32
Electric heating
Electric heater capacity kw/H 12 15 18 27 27 36 45 48 51
Exhaust mm 125 125 125 200 200 250 350 350 400
Electricity spec Voltage V 220 or 380 380
Power consumption
(steam / electric)		 Hz
kW/h		 50 or 60,
0.8 / 12.8		 50 or 60,
0.8/15.8		 50 or 60,
0.8/18.8		 50 or 60,
1.2/28.2		 50 or 60,
1.5/28.5		 50 or 60,
3/39		 50 or 60,
6 / 49.4		 50 or 60,
6 / 52.4		 50 or 60,
6 / 56.9
Exterior dimension WxDxH mm 880 x 1290
x 1690		 980 x 1300
x 1700		 980 x 1450
x 1700		 1090 x 1600
x 1890		 1240 x 1570
x 2010		 1440 x 1780
x 2170		 1690 x 1830
x 2490		 1690 x 1900
x 2500		 1890 x 2240
x 2720
Weight kg 380 420 490 540 640 850 1080 1120 1400
  • The above specifications can be changed (improvement/installation environment/etc.).
  • TILTING function – Available for machines with more than 100kg capacity.
  • Can be customized for specific purpose or request(clean rooms/hospitals/hotels/industrial laundries/etc.).
